Gap waveguide slot array antenna based on a metal-only solution using additive manufacturing with multifunctional sum/difference radiation pattern.

 0 Người đánh giá. Xếp hạng trung bình 0

Tác giả: Manuel Arrebola, Sergio M Feito, José Rico-Fernández, Álvaro F Vaquero

Ngôn ngữ: eng

Ký hiệu phân loại: 972.8202 *Central America

Thông tin xuất bản: England : Scientific reports , 2025

Mô tả vật lý:

Bộ sưu tập: NCBI

ID: 66718

This work presents an array of slot-type elements fed by a corporate network, achieving several radiation patterns in the mm-Wave band. The antenna is based on a metal-only structure, with a feeding network implemented using Groove Gap Waveguide technology, resulting in a low-loss, highly scalable solution. The radiating elements are slots in a 1 × 8 array configuration, which are excited through three waveguide ports. The proposed feeding network allows for a sum pattern that can also steer the beam depending on the feeding port. Additionally, a difference pattern can be obtained. The proposed design is manufactured using metal-only additive manufacturing with Laser Powder Bed Fusion. The prototype is measured in an anechoic chamber, showing a high agreement with simulation for each possible pattern. Furthermore, the antenna is evaluated in a planar range, demonstrating the high isolation of the proposed Groove Gap Waveguide. Overall, the antenna exhibits over 90% efficiency and four different radiation patterns, making it an attractive solution for mm-Wave antennas in multifunctional applications.
